APPLICATION: Designed for the flexible connection between the riser and manifold or aound the ball joint of offshore drilling rigs. Specially used to withstand flexing and high pressure encountered in offshore applications.

Standards: API spec 16C / ISO

API  Monogram No.: 16C-0486

TEMPERATURE:

Rating A: -4 ℉to +180℉ (-20℃ to +82℃)

Rating B: -4 ℉to +212℉ (-20℃ to +100℃)

Rating K: -75 ℉to +180℉ (-60℃ to +82℃)

FSLs: FSL 0~3

CONSTRUCTION:

Tube: Modified NBR or HNBR Black resisting abrasion, corrosion, oil, drilling muds and H2S.

Reinforcement: Multiple layers of steel cable and adhesion fabric

Cover: Modified Nitrile Black

COUPLINGS: Swaged-meets NACE MR0175

OPTIONS: Safety clamps, hose lift eyes and SS armor available upon request

Type	ID		OD		WP		TP		Fire-Resistant	Safety Factor	FSL	Min Bengding Radius	Weight	Max length
	mm	in	mm	inch	psi	MPa	psi	MPa				m	kg/m	m
JLG-SP-51X105	51	2	162	6.38	15000	105	22500	157.5	Yes	2.25	FSL3	1.2	51.6	45
JLG-SP-76X105	76	3	195	7.68	15000	105	22500	157.5	Yes	2.25	FSL3	1.4	68.3	45
JLG-SP-87X105	87	3.5	224	8.82	15000	105	22500	157.5	Yes	2.25	FSL3	1.4	78.5	45
JLG-SP-102X105	102	4	247	9.72	15000	105	22500	157.5	Yes	2.25	FSL3	1.5	86.5	45
