APPLICATION: Fire rated hydraulic hose assemblies for land and topside BOP applications.Armor BOP hoses are complying with API 16D guidelines to meet and exceed OD/1000/499 flame testing at 1300℉(704 ℃) for 5 minutes.

TEMPERATURE: -40 ℉to +250℉ (-40℃ to +121℃)

CONSTRUCTION:

Tube: Nitrile Black oil resistant synthetic rubber

Reinforcement: Multiple layers of steel cable and adhesion fabric

Cover: Fiber glass impregnated, flame resistant rubber

COUPLINGS: Globalspiral couplings

OPTIONS: Quick disconnects are available upon request

Type	ID		OD		WP		TP		Fire-Resistant	Safety Factor	Min Bengding Radius	Weight	Max length
	mm	in	mm	inch	psi	MPa	psi	MPa			mm	kg/m	m
BH-25X21	25	1	45	1.77	3000	21	4500	31.5	Yes	4	381	2.7	45
BH-32X21	32	1-1/4	54	2.13	3000	21	4500	31.5	Yes	4	457	3.7	45
BH-38X21	38	1-1/2	60	2.36	3000	21	4500	31.5	Yes	4	559	4.5	45
BH-51X21	51	2	75	2.95	3000	21	4500	31.5	Yes	4	686	5.8	45
BH-25X35	25	1	46	1.81	5000	35	7500	52.5	Yes	4	381	3.1	45
BH-32X35	32	1-1/4	58	2.28	5000	35	7500	52.5	Yes	4	457	4.9	45
BH-38X35	38	1-1/2	65	2.56	5000	35	7500	52.5	Yes	4	559	5.8	45
BH-51X35	51	2	80	3.15	5000	35	7500	52.5	Yes	4	686	8.4	45
